AD628
Rev. G | Page 14 of 20
6
2
3
1
8
7
5
4
+IN
100kΩ
CFILT
VREF
10kΩ
AD628
+VS
HP3561A
SPECTRUM ANALYZER
10kΩ
10kΩ
+IN
–IN
G = +0.1
+IN
–IN
–IN
100kΩ
10kΩ
10kΩ
OUT
–VS
RG
Figure 27. Noise Tests
