Preliminary Technical Data
AD8223
Rev.
PrA | Page 9 of 20
1k
100
10
11k
10
100
FREQUENCY (Hz)
Figure 8. Current Noise Spectral Density vs. Frequency
18
0
–12
10
CMV (V)
16
14
12
10
8
6
4
2
–10
–8
–6
–4
–2
0
2
4
6
8
VS = ±12V
VS = ±5V
VS = ±2.5V
Figure 9. IBIAS vs. CMV
1s/DIV
0.71pA/DIV
Figure 10. 0.1 Hz to 10 Hz Current Noise (0.71 pA/Div)
1s/DIV
0.5µV/DIV
G = 5
G = 1000
Figure 11. 0.1 Hz to 10 Hz RTI and RTO Voltage Noise
120
30
1100k
FREQUENCY (Hz)
10
100
1k
10k
110
100
90
80
70
60
50
40
G = 5
G = 1000
G = 10
G = 100
Figure 12. CMRR vs. Frequency, ±12 VS
120
30
1100k
FREQUENCY (Hz)
10
100
1k
10k
110
100
90
80
70
60
50
40
G = 5
G = 1000
G = 10
G = 100
Figure 13. CMRR vs. Frequency, VS = +5 V
