background image
Supports up to 2 TEKBAT-01 Li-Ion rechargeable batteries
Cell chemistry
Li-lon
Nominal capacity
6700 mAh
Voltage
14.52 VDC
Weight
450 g/1lb
Operating time, typical
Up to 4 hours single battery
Up to 8 hours dual batteries
Hot swappable
Physical characteristics
Dimensions
Instrument only
Height
210 mm (8.26 in)
Width
344 mm (13.54 in)
Depth
40.4 mm (1.59 in)
Instrument with battery pack
Height
210 mm (8.26 in)
Width
344 mm (13.54 in)
Depth
78 mm (3.07 in)
Weight
Instrument only
1.8 kg (4 lbs)
Instrument with battery pack
3.2 kg (7 lbs) – one battery
3.6 kg (8 lbs) – two batteries
Rackmount configuration
5U
Cooling clearance
2 in required on left side, right side and rear of the instrument
2 Series MSO Datasheet
www.tek.com 22
