6.2 Electrostatic Discharge (ESD) Extended Automotive Ratings

over recommended operating conditions (unless otherwise noted)

VALUE

UNIT

324-ball ZCZ-Q1 Package

V(ESD)

Electrostatic

Discharge

(ESD)

Human body model (HBM), per AEC-Q100-002(1)

±2000

Charged device model (CDM), per AEC-

Q100-011

All pins

±500

Corner balls on 324-ball

ZCZ:

A1, A18, V1, V18

±750

256-ball ZEJ-Q1 Package

V(ESD)

Electrostatic

Discharge

(ESD)

Human body model (HBM), per AEC-

Q100-002(1)

Human body model

(HBM), per AEC-

Q100-002(1)

±2000

Charged device model (CDM), per AEC-

Q100-011

All pins

±500

Corner balls on 256-ball

ZCZ:

A1, A16, T1, T16

±750

(1)

AEC Q100-002 indicates that HBM stressing shall be in accordance with the ANSI/ESDA/JEDEC JS-001 specification

6.3 Electrostatic Discharge (ESD) Industrial Ratings

over recommended operating conditions (unless otherwise noted)

VALUE

UNIT

324-ball ZCZ Package

V(ESD)

Electrostatic

Discharge

(ESD)

Human-body model (HBM), per ANSI/ESDA/JEDEC JS-001(1)

±2000

Charged-device model (CDM), per ANSI/ESDA/JEDEC JS-002(2)

±500

304-ball ZFG package

V(ESD)

Electrostatic

Discharge

(ESD)

Human-body model (HBM), per ANSI/ESDA/JEDEC JS-001(1)

±2000

Charged-device model (CDM), per ANSI/ESDA/JEDEC JS-002(2)

±500

256-Ball ZEJ package

V(ESD)

Electrostatic

Discharge

(ESD)

Human-body model (HBM), per ANSI/ESDA/JEDEC JS-001(1)

±2000

Charged-device model (CDM), per ANSI/ESDA/JEDEC JS-002(2)

±500

293-ball ZNC package

V(ESD)

Electrostatic

Discharge

(ESD)

Human-body model (HBM), per ANSI/ESDA/JEDEC JS-001(1)

±2000

Charged-device model (CDM), per ANSI/ESDA/JEDEC JS-002(2)

±500

(1)

JEDEC document JEP155 states that 500V HBM allows safe manufacturing with a standard ESD control process.

(2)

JEDEC document JEP157 states that 250V CDM allows safe manufacturing with a standard ESD control process.

6.4 Power-On Hours (POH) Summary

over recommended operating conditions (unless otherwise noted)(1) (2) (3)

Parameter

EXTENDED INDUSTRIAL

EXTENDED AUTOMOTIVE

Operating Junction Temperature (Tj)

–40

℃ to 125℃

–40

℃ to 150℃

POH @ Temp Profile

R5F = 400MHz(5)

(6)

100K @ 105

℃ (100% @ 105℃)

25K @ 125

℃ (100% @ 125℃)

20K @ Automotive Temp Profile(4)

R5F = 500MHz

(Default)

55K @ 105

℃ (100% @ 105℃)

15K @ 125

℃ (100% @ 125℃)

20K @ Automotive Temp Profile(4)

(1)

This information is provided solely for your convenience and does not extend or modify the warranty provided under TI's standard

terms and conditions for TI semiconductor products.
