Schottky Rectifier

S20SC9M

www.iscsemi.com

2

ELECTRICAL CHARACTERISTICS

SYMBOL

PARAMETER

CONDITIONS

MAX

UNIT

VF

Maximum Instantaneous Forward Voltage IF= 10A ; TC= 25℃

0.75

V

IR

Maximum Instantaneous Reverse Current Rated DC Voltage, TC= 25℃

10

mA

PACKAGE OUTLINE (UNIT: mm):
