27

※The values are measured data for reference, not guaranteed.

Application

・Magnetic field generated in charge is shield, and do not affect the other elements.

・It is improved magnetic rotation and charging efficiency, too.

FFSW

Magnetic

field

Coil

● PET with adhesive layer

● Ferrite sheet

● Double-sided adhesive tape

Material

SMARTPLY

／FFSW

Properties

Frequency［MHz］

0

100

200

300

400

500

600

700

0.01

0.1

1

10

μ'

μ"

● It is higher permeability magnetic sheet which is suitable for magnetic shield and improving

performance of wireless charging system according to international standard around 100kHz

such as Qi standard.

● S

intered ferrite material with flexibility enables higher drop impact resistance.

● Suitable for thinner design of module. (Total thickness of product: 0.21mm)

● C

ustom profile is available upon request.

Feature

Thinner and flexible ferrite sheet for wireless charging

■ Permeability

■ Wireless charging system

■ Charging efficiency between antennas.

◆Measurement results

◆Test specification

64.6%

87.7%

50%

60%

70%

80%

90%

2.9%

Sample

Sample

Spectrum

Analyzer

Signal

Generator

Operating frequency

Gap between two antennas

100kHz

10mm

φ50mm

Sample

FFSXｰH（μ≒110） FFSW

Transmission

Charging efficiency is improved !!

Receiving antenna

Transmission antenna

Antenna size

Reference

Installation

Installation

D

①

②

③

②

③

B

Ａ,B：Soft ferrite

C,D：Profile(PET with adhesive layer)

①PET with an adhesive layer

②Ferrite sheet

③Double-sided adhesive tape

Adhesive layer

FFSW-0.1-5060T

A

B

C

D

50

60

52

62

Part No.

Unit：mm

E

F

0.1

0.21

※Custom designs available. Please contact our sales representative for further information.
