AS7038RB
Functional Description
Datasheet
• PUBLIC
DS000726
• v2-00 • 2021-Jun-02
126
│ 24
Figure 10:
LED Drivers
7.1.2
LED Driver Configuration
LED_CFG Register (Address 0x10)
Figure 11:
LED_CFG Register
Addr: 0x10
LED_CFG
Bit
Bit Name
Default
Access
Bit Description
7
sigref_en
0
RW
Signal reference: Is required for all analog
blocks
(except PD_Amp or light-to-frequency
operation)
0: Disable signal reference
1: Enable signal reference
X=4
Sequencer
VD1
VD2
max.
compliance
Q
Q
SET
CL R
S
R
write 1 to register
irq_led_supply_low
ledX_supply
_low
and irq_led_
supply_low
currX
ledX_en
man_mode
man_sw_ledX
ledX_mode
VD3
X=1
X=2
X=3
D1
D2
D3
D4
VD4
