background image
Document Feedback
AS7331
Functional Description
Datasheet
• PUBLIC
DS001047
• v4-00 • 2023-Mar-24
71
│ 46
Figure 41:
Register Access Overview
Address(1)
[hex]
Access in Configuration State
Access in Measurement State
Write
Read
Write (1 Byte)
Read (2 Bytes)
0
OSR
OSR
OSR + STATUS
1
TEMP
2
AGEN
MRES1 (A)
3
MRES2 (B)
4
MRES3 (C)
5
OUTCONV_L(2)
6
CREG1
OUTCONV_H(2)
7
CREG2
8
CREG3
9
BREAK
A
EDGES
B
OPTREG
(1)
The 4 MSB bits of the register address are ignored.
(2)
OUTCONV is only available in SYND measurement mode with bit
CREG2:EN_TM = “1”. The least significant byte
comes first.
7.8.6
I²C General Procedure to Start with the AS7331
After applying the power supply voltage, the AS7331 is in the configuration state, but in the power
down mode. The user can now set up the device for the application by writing the control registers.
The success of the configuration can be proven by reading the control registers.
Before starting a measurement, the state must be changed to the Measurement state. The last three
bits (DOS) of the register OSR should be loaded with 011b. Now a conversion can be started with the
measurement mode, which is selected by CREG3:MMODE. A falling slope of the output pin READY
indicates the start. The rising edge at pin READY signals the end of conversion, and the measurement
results can be read via I²C communication.
If a new configuration should be implemented, the device’s state needs to be changed to the
configuration state. Therefore the value 010b should be written into the bits OSR:DOS. This operation
resets all measurement result registers to 00h, while the configuration registers keep their actual
values. Afterward, the new configuration can be done.
