E3S-A

2

Accessories (Order Separately)

Insert-type Long Slit

Mutual Interference Prevention Filters

Reflectors/Other Accessories

Note: When using any Reflector other than the provided one, use a sensing distance of approximately 0.7 times the typical value as a guide.

* Values in brackets are the minimum required distance between the Sensor and Reflector.

Sensing method Appearance

Connection

method

Sensing distance

Functions

Model

NPN output

PNP output

Diffuse-reflective

Sensors

Pre-wired

---

E3S-AD13 2M

E3S-AD33 2M

E3S-AD23 2M

E3S-AD43 2M

---

E3S-AD11 2M

E3S-AD31 2M

E3S-AD21 2M

E3S-AD41 2M

---

E3S-AD12 2M

E3S-AD32 2M

E3S-AD22 2M

E3S-AD42 2M

Connector

(M12)

---

E3S-AD18

E3S-AD38

E3S-AD16

E3S-AD36

E3S-AD17

E3S-AD37

Pre-wired

---

E3S-AD63 2M

E3S-AD83 2M

E3S-AD73 2M

E3S-AD93 2M

---

E3S-AD61 2M

E3S-AD81 2M

E3S-AD71 2M

E3S-AD91 2M

---

E3S-AD62 2M

E3S-AD82 2M

E3S-AD72 2M

E3S-AD92 2M

Connector

(M12)

---

E3S-AD68

E3S-AD88

E3S-AD66

E3S-AD86

E3S-AD67

E3S-AD87

Slit width

Sensing distance

Minimum sensing

object (typical)

Model

Quantity

Remarks

0.5 mm

× 11.1 mm

500 mm

0.2-mm dia.

E39-S46

1 of each for Emitter/

Receiver (4 Slits total)

Slits can be used with the E3S-

AT

@@ Through-beam

Sensor.

➜Page 10

1 mm

× 11.1 mm

1.1 m

0.4-mm dia.

2 mm

× 13.6 mm

2.5 m

0.8-mm dia.

1 of each for Emitter/

Receiver (2 Slits total)

Sensing distance

Model

Quantity

Remarks

2.4 m

E39-E6

2 of each for Emitter/Receiver

(4 Filters total)

Can be used with the E3S-AT

@@ Through-beam Sensor.

➜ Page 11

Name

Sensing distance (typical)

Model

Quantity

Remarks

Reflectors

2 m (100 mm) *

(rated value)

E39-R1

1

Provided with E3S-AR

@@ Retro-reflective Sensor.

Small Reflectors

1.3 m (100 mm) *

E39-R3

1

---

600 mm (70 mm) *

E39-R4

1

---

Tape Reflectors

450 mm (100 mm) *

E39-RS1

1

Enables MSR function.

700 mm (100 mm) *

E39-RS2

1

900 mm (100 mm) *

E39-RS3

1

Optical Axis

Confirmation Reflector

---

E39-R5

1

Used to check optical axis for the E3S-AT

@@

Through-beam Sensor.

Horizontal

100 mm (wide view)

Timer

Self Diagnosis

200 mm

Timer

Self Diagnosis

Turbo

700 mm

Timer

Self Diagnosis

Turbo

100 mm (wide view)

200 mm

700 mm

Vertical

100 mm (wide view)

Timer

Self Diagnosis

200 mm

Timer

Self Diagnosis

Turbo

700 mm

Timer

Self Diagnosis

100 mm (wide view)

200 mm

700 mm
