MICRO SWITCH™ Miniature Sealed Basic Switches

MICRO SWITCH™ JE SERIES AUXILIARY ACTUATORS FOR THE MICRO SWITCH™ SE SERIES SWITCHES

(specifications when assembled to 1SE1)

Description

Actuator

Length

Operting

Force

max.

Release

Force min.

Pretravel

max.

Overtravel

min.

Differential

Travel max.

Operating

Point

nom.

Free

Position

nom.

(see Figure 5)

Straight leaf

(mounting

hardware

included)

16,8 mm

[0.66 in]

340 g

[12 oz]

57 g

[2 oz]

3,81 mm

[0.150 in]

0,38 mm

[0.015 in]

0,64 mm

[0.025 in]

11,2 mm

[0.44 in]

15 mm

[0.59 in]

(see Figure 6)

Roller leaf, roller

rotated 90° to

switch axis

(mounting

hardware

included)

16,8 mm

[0.66 in]

340 g

[12 oz]

57 g

[2 oz]

3,81 mm

[0.150 in]

0,38 mm

[0.015 in]

0,64 mm

[0.025 in]

16,3 mm

[0.64 in]

20,1 mm

[0.79 in]

(see Figure 7)

Roller leaf

(mounting

hardware

included)

15,2 mm

[0.60 in]

340 g

[12 oz]

57 g

[2 oz]

3,81 mm

[0.150 in]

0,38 mm

[0.015 in]

0,64 mm

[0.025 in]

16,3 mm

[0.64 in]

20,1 mm

[0.79 in]

(see Figure 8)

Roller leaf

[reversed]

(mounting

hardware

included)

15,2 mm

[0.60 in]

340 g

[12 oz]

57 g

[2 oz]

3,81 mm

[0.150 in]

0,38 mm

[0.015 in]

0,64 mm

[0.025 in]

16,3 mm

[0.64 in]

20,1 mm

[0.79 in]

(see Figure 9)

Roller lever

13,7 mm

[0.540 in]

170 g

[6 oz]

28 g

[1 oz]

2,54 mm

[0.100 in]

0,25 mm

[0.01 in]

0,41 mm

[0.016 in]

16,3 mm

[0.64 in]

18,8 mm

[0.74 in]

(see Figure 10)

Tandem roller

lever

17,8 mm

[0.700 in]

482 g

[17 oz]

113 g

[4 oz]

2,54 mm

[0.100 in]

0,15 mm

[0.006 in]

0,3 mm

[0.012 in]

16,8 mm

[0.66 in]

19,3 mm

[0.76 in]

** Travel characteristics on tandem actuators vary with actual basic switch characteristics

MICRO SWITCH™ JM SERIES AUXILIARY ACTUATORS FOR THE MICRO SWITCH™ XE SERIES SWITCHES

(specifications when assembled to 1XE1)

Description

Actuator

Length

Operating

Force

max.

Release

Force

min.

Pretravel

max.

Overtravel

min.

Differential

Travel

max.

Operating

Point

nom.

Free

Position

nom.

(see Figure 11)

Straight leaf

(mounting

hardware

included)

11,4 mm

[0.45 in]

595 g

[21 oz]

85 g

[3 oz]

3,18 mm

[0.125 in]

0,23 mm

[0.009 in]

0,3 mm

[0.012 in]

10,8 mm

[0.425 in]

14 mm

[0.55 in]

(see Figure 12)

Roller leaf

(mounting

hardware

included)

9,5 mm

[0.375 in]

595 g

[21 oz]

85 g

[3 oz]

3,18 mm

[0.125 in]

0,23 mm

[0.009 in]

0,3 mm

[0.012 in]

15,9 mm

[0.625 in]

19,1 mm

[0.75 in]

** Travel characteristics on tandem actuators vary with actual basic switch characteristics
