CDP2DP141MBD Scheda tecnica(PDF) 3 Page - StarTech.com Ltd. |
|
|
|||||||||||||||||||||||||||||
CDP2DP141MBD Scheda tecnica(HTML) 3 Page - StarTech.com Ltd. |
|
|
3 / 4 page  AV Input USB-C DisplayPort - 1.4 AV Output DisplayPort USB-C Audio Yes Chipset ID Chrontel - CH7213C-BF Texas Instruments - TUSB544 VIA Labs - VL170 Performance Video Revision DisplayPort 1.4 Maximum Digital Resolutions DisplayPort: 7680x4320 (8K) / 60Hz USB-C: 7680x4320 (8K) / 60Hz Wide Screen Supported Yes Bandwidth HBR3 Audio Specifications DisplayPort - 7.1 Channel Audio USB-C - 7.1 Channel Audio Connector(s) Connector A 1 - USB-C (24 pin) DisplayPort Alt Mode 1 - Thunderbolt 3 USB-C (24-pin) (40Gbps) Connector B 1 - DisplayPort (20 pin) Special Notes / Requirements System and Cable Requirements Your USB-C device must support DisplayPort Alt Mode to work with this cable To achieve 8K resolutions, your source and your destination must support DisplayPort 1.4 This cable is not compatible with the Surface Dock 2 Environmental Operating Temperature 0C to 45C (32F to 113F) |
|
|
