ST7SCR
88/102
EMC CHARACTERISTICS (Cont’d)
Multisupply Configuration
When several types of ground (VSS, VSSA, ...) and
power supply (VDD, VDDA, ...) are available for any
reason (better noise immunity...), the structure
shown in Figure 44 is implemented to protect the
device against ESD.
Figure 44. Multisupply Configuration
VDDA
VSSA
VDDA
VDD
VSS
BACK TO BACK DIODE
BETWEEN GROUNDS
VSSA
