background image
ST207EB - ST207EC
Electrical characteristics
7/15
Table 8.
Timing characteristics
(C1 - C4 = 0.1 µF, VCC = 5V ± 5%, TA = min. to max., unless otherwise specified. Typical
values are referred to TA = 25°C).
Symbol
Parameter
Test condition
Min.
Typ.
Max.
Unit
DR
Maximum data rate
RL = 3kΩ to 7kΩ
CL= 50pF to 1000pF
one transmitter switching
150
240
Kbps
RL = 3kΩ to 7kΩ CL= 50pF to 150pF
one transmitter switching
230
300
Kbps
tPHLR
tPLHR
Receiver propagation
delay
All drivers loaded with 3K
Ω to GND
0.2
10
µs
tPHLT
tPLHT
Transmitter propagation
delay
RL = 3kΩ CL= 2500pF
All transmitter loaded
23
µs
SR
Transition-region slew
rate
TA = 25°C RL = 3 to 7 kΩ VCC = 5 V
CL = 50pF to 1000pF measured from
+3V to -3V or -3V to +3V
3
7
30
V/µs
