HD74LVC1G97
Rev.4.00 Jun. 29, 2004 page 2 of 10
Function Table
Inputs
Output
IN2
IN1
IN0
Y
LL
L
L
L
L
HL
L
HL
H
L
H
HH
HL
L
L
HL
H
H
HH
L
L
HH
H
H
H : High level
L : Low level
Pin Arrangement
(Bottom view)
(Top view)
Y
16
34
IN0
Height 0.5 mm
0.5 mm pitch
0.17 mm 6–Ball (CP)
0.23 mm 6–Ball (CL)
0.9 mm
GND
VCC
IN1
IN2
5
2
Pin#1 INDEX
Logic Diagram
IN0
IN1
IN2
Y
