STTH302
2/5
Symbol
Parameter
Test Conditions
Min.
Typ.
Max.
Unit
IR *
Reverse leakage current
Tj = 25°C
VR =VRRM
3
µA
Tj = 125°C
475
VF **
Forward voltage drop
Tj = 25°C
IF =3A
0.95
V
Tj = 125°C
0.66
0.75
Pulse test:*tp=5ms,
δ <2%
** tp = 380
µs, δ <2%
To evaluate the maximum conduction losses use the following equations:
P=0.60xIF(AV) + 0.05 IF
2
(RMS)
STATIC ELECTRICAL CHARACTERISTICS
Symbol
Parameter
Test conditions
Min.
Typ.
Max.
Unit
trr
Reverse recovery
time
IF =1A dIF/dt = - 50A/
µs
VR = 30V
Tj = 25°C
35
ns
tfr
Forward recovery
time
IF =3A dIF/dt = 50A/
µs
VFR =1.1xVF max
Tj = 25°C
70
ns
VFP
Forward recovery
voltage
Tj = 25°C
1.6
V
DYNAMIC ELECTRICAL CHARACTERISTICS
