Section 2 CPU

Rev.1.00 Jun. 07, 2006 Page 38 of 1102

REJ09B0294-0100

2.7

Instruction Set

The H8SX CPU has 87 types of instructions. The instructions are classified by function as shown

in table 2.1. The arithmetic operation, logic operation, shift, and bit manipulation instructions are

called operation instruction in this manual.

Table 2.1

Instruction Classification

Function

Instructions

Size

Types

Data transfer

MOV

B/W/L

MOVFPE*

6, MOVTPE*6

POP, PUSH*

W/L

LDM, STM

MOVA

B/W*

Block transfer

EEPMOV

MOVMD

B/W/L

MOVSD

Arithmetic

operations

ADD, ADDX, SUB, SUBX, CMP, NEG, INC, DEC

B/W/L

DAA, DAS

ADDS, SUBS

MULXU, DIVXU, MULXS, DIVXS

B/W

MULU, DIVU, MULS, DIVS

W/L

MULU/U, MULS/U

EXTU, EXTS

W/L

TAS

MAC

—

LDMAC, STMAC

—

CLRMAC

—

Logic operations

AND, OR, XOR, NOT

B/W/L

Shift

SHLL, SHLR, SHAL, SHAR, ROTL, ROTR, ROTXL, ROTXR

B/W/L

Bit manipulation

BSET, BCLR, BNOT, BTST, BAND, BIAND, BOR, BIOR,

BXOR, BIXOR, BLD, BILD, BST, BIST

BSET/EQ, BSET/NE, BCLR/EQ, BCLR/NE, BSTZ, BISTZ

BFLD, BFST
