80D

Vishay Sprague

Aluminum Capacitors

+ 85 °C, Snap-In

www.vishay.com

For technical questions, contact: aluminumcaps4@vishay.com

Document Number: 42060

218

Revision: 27-Aug-08

FEATURES

• High ripple capability

• Molded cover available in 2 and 3 terminal

design with standoffs

Fig.1 Component Outlines

Available

Pb-free

QUICK REFERENCE DATA

DESCRIPTION

VALUE

Nominal case size

ØD x L in mm

0.866" x 0.984" (22.0 x 25.0)

to 1.38" x 3.15" (35.0 x 80.0)

Operating temperature

- 40 °C to + 85 °C

Rated capacitance

range, CR

82 µF to 56 000 µF

Tolerance on CR

- 10 %, + 30 %

Rated voltage range, UR

6.3 WVDC to 250 WVDC

Termination

Snap mount or 2 and 3

terminal straight leads

Life validation test

at 85°C

2000 h:

Δ CAP ≤ 15 % from initial

measurement.

Δ ESR ≤ 1.5 x initial

specified limit.

Δ DCL ≤ initial

specified limit

Shelf life at 85°C

500 h:

Δ CAP ≤ 15 % from initial

measurement.

Δ ESR ≤ 1.3 x initial

specified limit.

Δ DCL ≤ 2 x initial

specified limit

DC leakage current

I = K

K = 4.0 at + 25 °C

I in µA, C in µF, V in Volts

cv

RIPPLE CURRENT MULTIPLIERS

TEMPERATURE

AMBIENT TEMPERATURE

MULTIPLIERS

+ 55 °C

+ 65 °C

+ 75 °C

+ 85 °C

2.0

1.7

1.4

1.0

FREQUENCY (Hz)

WVDC

50 TO 60

300 TO 1000

1000 AND

UP

0 - 49

50 - 199

200 - 250

0.85

0.83

0.80

1.10

1.15

1.30

1.15

1.20

1.40

ESL (TYPICAL VALUES AT 1 MHz TO 10 MHz)

Nominal

Diameter

0.866

(22.0)

0.984

(25.0)

1.18

(30.0)

1.38

(35.0)

Typical

ESL (nH)

6.0

8.0

10.0

12.0

DIMENSIONS in inches (millimeters)

CASE

CODE

DIAMETER

LENGTH

CASE

CODE

DIAMETER

LENGTH

D + 0.039 - 0 (+1.0 - 0)

L ± 0.079 (2.0)

D + 0.039 - 0 (+ 1.0 - 0)

L ± 0.079 (2.0)

HA

0.87 (22.0)

1.00 (25.0)

KC

1.18 (30.0)

1.38 (35.0)

HB

0.87 (22.0)

1.18 (30.0)

KD

1.18 (30.0)

1.57 (40.0)

HD

0.87 (22.0)

1.57 (40.0)

KE

1.18 (30.0)

2.00 (50.0)

JA

1.00 (25.0)

MB

1.38 (35.0)

1.18 (30.0)

JB

1.00 (25.0)

1.18 (30.0)

MC

1.38 (35.0)

JC

1.00 (25.0)

1.38 (35.0)

MD

1.38 (35.0)

1.57 (40.0)

JD

1.00 (25.0)

1.57 (40.0)

ME

1.38 (35.0)

2.00 (50.0)

JE

1.00 (25.0)

2.00 (50.0)

MF

1.38 (35.0)

2.50 (63.0)

KA

1.18 (30.0)

1.00 (25.0)

MG

1.38 (35.0)

3.18 (80.0)

KB

1.18 (30.0)
