7 / 28 page

AD8295

Rev. 0 | Page 7 of

ABSOLUTE MAXIMUM RATINGS

Table 6.

Parameter

Rating

Supply Voltage

±18 V

Output Short-Circuit Current

Indefinite

Input Voltage

Common-Mode

±VS

Differential

±VS

Storage Temperature Range

−65°C to +130°C

Operating Temperature Range1

−40°C to +125°C

Lead Temperature (Soldering, 10 sec)

300°C

Junction Temperature

130°C

ESD (Human Body Model)

2000 V

ESD (Charge Device Model)

500 V

ESD (Machine Model)

200 V

1 Temperature range for specified performance is −40°C to +85°C. See the

Typical Performance Characteristics section for expected operation from

85°C to 125°C.

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL CHARACTERISTICS

Specifications are provided for a device in free air.

Table 7.

Package

θJA

Unit

16-Lead LFCSP_VQ

°C/W

ESD CAUTION
