ADA4075-2ARZ-R7 datasheet(4/24 Pages) AD

4 / 24 page

ADA4075-2

Rev. 0 | Page 4 of 24

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

Supply Voltage

±20 V

Input Voltage

±VSY

Input Current1

±10 mA

Differential Input Voltage

±1 V

Output Short-Circuit Duration to GND

Indefinite

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +125°C

Junction Temperature Range

−65°C to +150°C

Lead Temperature (Soldering, 60 sec)

300°C

1 The input pins have clamp diodes to the power supply pins.

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL RESISTANCE

θJA is specified for the worst-case conditions, that is, a device

soldered in a circuit board for surface-mount packages. This

was measured using a standard 2-layer board.

Table 3. Thermal Resistance

Package Type

θJA

θJC

Unit

8-Lead SOIC

158

°C/W

POWER SEQUENCING

The op amp supplies must be established simultaneously with,

or before, any input signals are applied. If this is not possible,

the input current must be limited to 10 mA.

ESD CAUTION
