TS904

RAIL TO RAIL CMOS QUAD

OPERATIONAL AMPLIFIER (WITH STANDBY POSITION)

April 1999

.

RAIL TO RAIL INPUT AND OUTPUT

VOLTAGE RANGES

.

2SEPARATE STANDBY : REDUCED

CONSUMPTION (0.5

µA) AND HIGH IMPED-

ANCE OUTPUTS

.

SINGLE (OR DUAL) SUPPLY OPERATION

FROM 2.7V TO 16V

.

EXTREMELY LOW INPUT BIAS CURRENT :

1pA TYP

.

LOW INPUT OFFSET VOLTAGE : 5mV max.

.

SPECIFIED FOR 600

Ω AND 150Ω LOADS

.

LOW SUPPLY CURRENT : 200

µA/Ampli

.

SPICE MACROMODEL INCLUDED IN THIS

SPECIFICATION

CC

V

+

1

2

3

4

5

6

7

9

10

11

12

13

14

Non-inve rting Input 2

-

+

-

+

S tandby 1

Output 1

Non-inve rting input 1

Inverting Input 1

-

CC

V

Inve rting Inpu t 2

Output 2

8

15

16

Output 4

Inverting Input 4

Non-inverting input 4

Non-inverting input 3

Inve rting input 3

S tandby 2

Output 3

PIN CONNECTIONS (top view)

N

DIP16

(Plastic Package)

®

DESCRIPTION

The TS904 is a RAIL TO RAIL quad CMOS opera-

tional amplifier designed to operate with a single or

dual supply voltage.

The input voltage range Vicm includes the two

supply rails VCC

+ and VCC-.

The output reaches :

• VCC- +50mV

VCC

+ -50mV

with RL = 10k

Ω

• VCC- +350mV VCC+ -350mV with RL = 600Ω

This product offers a broad supply voltage operat-

ing range from 2.7V to 16V and a supply current of

only 200

µA/amp. (VCC = 3V)

Source and sink output current capability is typi-

cally 40mA (at VCC = 3V), fixed by an internal

limitation circuit.

The TS904 offers two separate STANDBY pins

• STANDBY 1 acting on the n°2 and

n

°3 operators

• STANDBY 2 acting on the n°1 and

n

°4 operators

They reduce the consumption of the corresponding

operators and put the outputs in a high impedance

state.

These two STANDBY pins should never stay not

connected.

STMicroelectronics is offering a quad op-amp with

the same features : TS902.

D

SO16

(Plastic Micropackage)

ORDER CODES

Part Number

Temperature Range

Package

ND

TS904I/AI

-40, +125

oC

••

1/12
