2 / 3 page

INCHANGE Semiconductor

isc Product Specification

isc Silicon PNP Power Transistors

TIP42/42A/42B/42C

ELECTRICAL CHARACTERISTICS

TC=25℃ unless otherwise specified

SYMBOL

PARAMETER

CONDITIONS

MIN

MAX

UNIT

TIP42

-40

TIP42A

-60

TIP42B

-80

VCEO(SUS)

Collector-Emitter

Sustaining Voltage

TIP42C

IC= -30mA; IB= 0

-100

VCE(sat)

Collector-Emitter Saturation Voltage

IC= -6A ;IB= -0.6A

-1.5

VBE(on)

Base-Emitter On Voltage

IC= -6A ; VCE= -4V

-2.0

TIP42

VCE= -40V; VEB= 0

TIP42A

VCE= -60V; VEB= 0

TIP42B

VCE= -80V; VEB= 0

ICES

Collector Cutoff Current

TIP42C

VCE= -100V; VEB= 0

-0.4

TIP42/42A

VCE= -30V; IB= 0

ICEO

Collector Cutoff Current

TIP42B/42C

VCE= -60V; IB= 0

-0.7

IEBO

Emitter Cutoff Current

VEB= -5V; IC= 0

-1.0

hFE-1

DC Current Gain

IC= -0.3A ; VCE= -4V

hFE-2

DC Current Gain

IC= -3A ; VCE= -4V

Current-Gain—Bandwidth Product

IC= -0.5A ;VCE= -10V

MHz

isc Website：www.iscsemi.cn
