Absolute Maximum Ratings

Thermal Information

DC Supply Voltage, VCC . . . . . . . . . . . . . . . . . . . . . . . . -0.5V to 6V

DC Input Diode Current, IIK

For VI < -0.5V or VI > VCC + 0.5V . . . . . . . . . . . . . . . . . . . . . .±20mA

DC Output Diode Current, IOK

For VO < -0.5V or VO > VCC + 0.5V . . . . . . . . . . . . . . . . . . . .±50mA

DC Output Source or Sink Current per Output Pin, IO

For VO > -0.5V or VO < VCC + 0.5V . . . . . . . . . . . . . . . . . . . .±50mA

DC VCC or Ground Current, ICC or IGND (Note 3) . . . . . . . . .±100mA

Operating Conditions

Temperature Range, TA . . . . . . . . . . . . . . . . . . . . . . -55

oC to 125oC

Supply Voltage Range, VCC (Note 4)

AC Types. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.5V to 5.5V

ACT Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4.5V to 5.5V

DC Input or Output Voltage, VI, VO . . . . . . . . . . . . . . . . . 0V to VCC

Input Rise and Fall Slew Rate, dt/dv

AC Types, 1.5V to 3V . . . . . . . . . . . . . . . . . . . . . . . . . 50ns (Max)

AC Types, 3.6V to 5.5V . . . . . . . . . . . . . . . . . . . . . . . . 20ns (Max)

ACT Types, 4.5V to 5.5V. . . . . . . . . . . . . . . . . . . . . . . 10ns (Max)

Thermal Resistance (Typical, Note 5)

θJA (oC/W)

PDIP Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

SOIC Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

175

Maximum Junction Temperature (Plastic Package) . . . . . . . . . . 150oC

Maximum Storage Temperature Range . . . . . . . . . .-65oC to 150oC

Maximum Lead Temperature (Soldering 10s) . . . . . . . . . . . . . 300oC

CAUTION: Stresses above those listed in “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress only rating and operation

of the device at these or any other conditions above those indicated in the operational sections of this speciﬁcation is not implied.

NOTES:

3. For up to 4 outputs per device, add

±25mA for each additional output.

4. Unless otherwise specified, all voltages are referenced to ground.

θJA is measured with the component mounted on an evaluation PC board in free air.

DC Electrical Speciﬁcations

PARAMETER

SYMBOL

TEST

CONDITIONS

VCC

(V)

25oC

-40oC TO

85oC

-55oC TO

125oC

UNITS

VI (V)

IO (mA)

MIN

MAX

MIN

MAX

MIN

MAX

AC TYPES

High Level Input Voltage

VIH

1.5

1.2

2.1

5.5

3.85

Low Level Input Voltage

VIL

1.5

0.3

0.9

5.5

1.65

High Level Output Voltage

(04)

VOH

VIH or VIL

-0.05

1.5

1.4

-0.05

2.9

-0.05

4.5

4.4

-4

2.58

2.48

2.4

-24

4.5

3.94

3.8

3.7

-75

(Note 6, 7)

5.5

3.85

-50

(Note 6, 7)

5.5

----

3.85

CD74AC04, CD74ACT04, CD74AC05, CD74ACT05
