10mm Ultra-Thin SMT DIP Rotaries

Series FR02

Upright • Screwdriver Actuated

TYPICAL SWITCH DIMENSIONS

P

FR02FC10P

(10.5)

.413

(1.0) Typ

.039

(1.75) Typ

.069

(2.54) Typ

.100

(1.27) Typ

.050

12 4

C

8

CL

0 1

9

(10.0)

.394

(0.2)

.008

(3.8) Dia

.150

(10.0)

.394

012

EF

(10.0)

.394

(0.2)

.008

(3.8) Dia

.150

(10.0)

.394

(13.0)

.512

(3.9)

.154

(0.2) Typ

.008

(0.1) Typ

.004

C

1

2

4

8

(2.54) Typ

.100

(0.5) Typ

.020

Decimal

Hexadecimal

PACKAGING

Each stick-tube contains 50 switches.

Switches must be ordered in 50-piece increments.

S

Stick-Tube

(16.0)

.630

(16.4)

.646

(540.0)

21.260

(10.5) Typ

.413

(2.0) Typ

.079

Overall Dia (330.0)

13.0

(6.5) R

.256

Switches must be ordered in 500-piece increments.

This packaging meets EIA-481-2 Standard.

R

Tape-Reel

(24.4)

.961

(80.0) Dia

3.150

(30.4) Max

1.197

3ϒMax

(0.4)

.016

(10.0)

.394

(4.1)

.161

(4.6)

.181

(2.1) Typ

.083

(24.0)

.945

(1.75)

.069

(11.5)

.453

(16.0) Typ

.630

(2.0) Typ

.079

(4.0) Typ

.157

(1.5) Dia Typ

.059

Direction of Feed

0 1

9

(10.3) Typ

.406

(1.2) Typ

.047

Each tape-reel of 550 pockets contains 500 switches.

Minimum Leader Length: 15.748” (400mm)

Minimum Trailer Length:

6.299” (160mm)
