(a)

(c)

(b)

(e)

(d)

1. PART NO. EXPRESSION :

(b) Dimension code

(c) Inductance code : 1R0 = 1.0uH

(a) Series code

2. CONFIGURATION & DIMENSIONS :

SUPERWORLD ELECTRONICS (S) PTE LTD

(d) Tolerance code : J = ±5%, K = ±10%, M = ±20%

(e) F : Lead Free

SDI322520 SERIES

WIREWOUND CHIP INDUCTORS

PG. 1

NOTE : Specifications subject to change without notice. Please check our website for latest information.

31.07.2008

S D I 3 2 2 5 2 0 - 1 R 0 M F

b) Operating temp. : -25°C to 85°C

c) Rated current : Base on temp. rise & L/L0A=10% Max.

4. GENERAL SPECIFICATION :

a) Ambient temp. : 20°C

2

3. SCHEMATIC :

1

AB

3.2±0.3

2.5±0.2

A

FH

CE

2.0±0.3

0.7 Min.

0.7 Min.

2.0 Ref.

IJ

1.5 Ref.

1.0 Ref.

Unit:m/m

F

B

E

J

I

I

PCB Pattern

E
