background image
3
9154AS–AUDR–09/09
ATR4252 [Preliminary]
20
AMPD
AM AGC output for pin diode
21
REF
Reference voltage 6V
22
AM LNA BIAS
Reference voltage for AM LNA IN
23
AM LNA IN
AM LNA input terminal
24
AM LNA SOURCE
AM LNA source terminal
25
CASCODE FILTER
AM Cascode filter terminal
26
AM LNA OUT
AM LNA output terminal
27
AMBIAS
Reference voltage for AMBUF IN
28
AMBUF IN
AM Buffer amplifier input, impedance matching
Paddle
GND
Ground paddle
Table 2-1.
Pin Description (Continued)
Pin
Symbol
Function
