ATVaultIC460

–Starter Kit

Atmel’s application note [7] presents examples of efficient and cost effective IP protection appli-

cations utilizing secure chips in various embedded systems.

1.5

Typical application

The ATVaultIC460 is a turnkey solution that combines powerful cryptographic capabilities and

secure data storage. A typical application of the ATVaultIC460 is Video Slot Gaming Machines.

Fraud, theft and embezzelment are the big fears of casinos so that they look for security inside

their gaming machines.

An ATVaultIC460 linked to the main processor of the machine allows authentication of the host

controller (casino) and of the slot machine. Moreover physical protection of the sensitive code/

data, data encryption, secure communication channel, data integrity checking are other security

features provided by the ATVaultIC460.

Figure 1-1.

Gaming Application

For more details about the solution, please refer to the Application Note ”How to secure Video

1.6

Ordering Information

1.6.1

Legal

A Non-Disclosure Agreement must be signed with ATMEL.

An Export License for cryptographic hardware/software must be granted.

1.6.2

Quotation and Volume

For the minimum order of quantity and the annual volume, please contact your local ATMEL

sales office.

Casino

Host Control

Gaming

Machine

Main

Processor

ATVaultIC460
