background image
Low-Power, Multifunction, Polyphase AFE
with Harmonics and Tamper Detect
46
______________________________________________________________________________________
Energy, Reactive Negative, Phase X = A/B/C (X.ERNEG)
(A: 0x1F4, B: 0x2E0, C: 0x3CC)
On every DSP cycle, the contents of the X.REA register are tested, and, if negative, absolute values are added to
this register. When this register overflows, the RNOV bit in the X.EOVER register is set.
Energy, Apparent, Phase X = A/B/C (X.ES) (A: 0x1F8, B: 0x2E4, C: 0x3D0)
On every DSP cycle, the contents of the X.APP register are added to this register. When this register overflows, the
SOV bit in the X.EOVER register is set.
Bit:
31
30
29
28
27
26
25
24
Name:
Reactive Energy Byte 3
Bit:
23
22
21
20
19
18
17
16
Name:
Reactive Energy Byte 2
Bit:
15
14
13
12
11
10
9
8
Name:
Reactive Energy Byte 1
Bit:
7
6
5
4
3
2
1
0
Name:
Reactive Energy Byte 0
Bit:
31
30
29
28
27
26
25
24
Name:
Apparent Energy Byte 3
Bit:
23
22
21
20
19
18
17
16
Name:
Apparent Energy Byte 2
Bit:
15
14
13
12
11
10
9
8
Name:
Apparent Energy Byte 1
Bit:
7
6
5
4
3
2
1
0
Name:
Apparent Energy Byte 0
