Industrial Panel PCs
Features
IPPC-6172F
17" SXGA TFT LCD Celeron® M Fanless
Industrial Panel PC with 2 x PCI Slots
Fanlesscoolingsystem
17"SXGATFTLCDwithtouchscreen
Intel®Celeron®MProcessorULV1GHz/512KBL2onboard
1GBDDR2SDRAMsystemmemory
24VDCpowersupply
OfferstwoexpansionslotsforPCIadd-oncard
DualLan,supportsoneGigabitLan
FrontUSBaccessandsystemresetfunction
Flat-sealedfrontpanel
Controlboxwithgull-wingdesignforeasyinstallationandmaintenance
FrontpanelNEMA4/IP65compliant
Heavy-dutyaluminumfrontpanel
Specifications
General
BIOS
Award®512KBFlashBIOS
Certifications
UL,CE,FCC,CCC,BSMI
Enclosure
Die-castflat-sealedfrontwithSGCCHousing
Dimension (W x H x D) 481.92x355.87x146mm(18.97"x14.01"x5.75")
Mounting
Panel,Rack(option)
OS Support
Windows2000,XPProfessionalandWinXPe
Power Input
10~30VDC
Power Output
+3.3V@8A,+5V@10A,+12V@4A,
+5Vsb@0.75A,-12V@1A
Power Supply
85W
Weight (Gross)
15Kg(33.06lbs)
System Hardware
CPU
IntelCeleronMULV1GHzwith512KBL2onboard
Chipset
Intel915GME
Memory
1GBDDR2240pinSDARM533MHz
LAN
10/100Base-TEthernetx1,10/100/1000Base-T
Ethernetx1
Expansion
2xhalf-lengthPCISlots(total25W)
Storage
1xCompactFlashSlot,
1xSATAHDDinterface(2.5"HDDbay)
I/Os
1xRS-232
5xUSB2.0(oneatfront)
2xPS2(Keyboard,Mouse)
1xVGAPort
1xParallelPort
Mic-in,Line-in,Line-out
LCD Display
Backlight Life
50,000hrs
Contrast Ratio
800:1
Display Size
17"
Display Type
SXGATFTLCD
Luminance
300cd/m2
Max. Colors
16.7M(RGB6-bit+FRCdata)
Max. Resolution
1280x1024
Viewing Angle (H/V°) 160/160
Touchscreen (Optional)
Lifespan
10millionstimestouchatsinglepoint
Light Transmission
>80%
Type
Analogresistive8-wire
Environment
Humidity
5~85%@40°C(non-condensing)
Ingress Protection
Frontpanel:NEMA4/IP65
Operating Temperature 0~50°C(32~122°F)
Storage Temperature -20~60°C(-4~140°F)
Vibration Protection
5~500Hz,1Grmsrandomvibration
Ordering Information
IPPC-6172F-X0AE
17"FanlessPanelPC,CeleronM,2xPCI
IPPC-6172F-R0AE
17"FanlessPanelPC,CeleronM,1GHz,2xPCI,TS
Introduction
TheIPPC-6172FisanIndustrialPanelPCwithfrontUSBaccess,supportsCeleronMULV1GHz,1GBDDR2memory,oneCompactFlashslotandtwoPCIexpansionslots.The
flat-sealedfrontpaneldesignforeasiercleaningandliquidrunoff.Alsothecontrolboxhasthegull-wingdesignforeasycomponentsinstallationandmaintenance.Thedesignof
fanlesscoolingsystemandspindle-freestoragemakesIPPC-6172Fadurableandreliableplatform.Afast-accessSATAHDDisoption.TwoPCIslotsmeetsdiverserequests.
