background image
Ferroxcube
RM cores and accessories
RM4/ILP
COIL FORMERS
General data SMD coil former
Winding data for RM4/ILP coil former (SMD)
PARAMETER
SPECIFICATION
Coil former material
phenolformaldehyde (PF), glass-reinforced, flame retardant in accordance with
“UL 94V-0”; UL file number E41429 (M)
Solder pad material
Maximum operating temperature
155 C, “IEC 60085”, class F
Resistance to soldering heat
“IEC 60068-2-20”, Part 2, Test Tb, method 1B, 350 C, 3.5 s
Solderability
“IEC 60068-2-20”, Part 2, Test Ta, method 1
NUMBER OF
SECTIONS
NUMBER OF
SOLDER
PADS
WINDING
AREA
(mm2)
WINDING
WIDTH
(mm)
AVERAGE
LENGTH OF
TURN
(mm)
TYPE NUMBER
1
8
3.75
3.0
20.7
CSVS-RM4/LP-1S-8PL
copper-tin alloy (CuSn), tin-lead alloy (SnPb) plated.
