Connectors

2-18

ADSP-BF506F EZ-KIT Lite Evaluation System Manual

When an emulator is used with the EZ-KIT Lite, the on-board debug

agent is bypassed.

Expansion Interface II Connectors (P2 and P4)

and P4 are board-to-board connectors providing signals for the SPI,

TWI, UART, SPORT, and GPIO signals of the processor. The connec-

tors are located on the upper edge of the board (one connector is on the

top and one is on the bottom). For more information, see “Expansion

Interface II” on page 1-11.

Expansion Interface II Connector (P3)

is a board-to-board connector providing signals for the PPI and GPIO

signals of the processor. The connector is located on the upper edge of the

board. For more information, see “Expansion Interface II” on page 1-11.

Part Description

Manufacturer

Part Number

50-position 0.1’’, SMT header

SAMTEC

TSSH-125-01-L-DV-A

Mating Connector

50-position 0.1’’, SMT socket

SAMTEC

SSW-125-22-F-D-VS

Part Description

Manufacturer

Part Number

70-position 0.1’’, SMT header

SAMTEC

TSSH-135-01-L-DV-A

Mating Connector

70-position 0.1’’, SMT socket

SAMTEC

SSW-135-22-F-D-VS
