100 / 114 page  100 CHAPTER 3: ELECTRICAL SPECIFICATIONS C3EN QMU to Q-5/Q-3 (External Mode) Timing Specifications The QMU to Q-5/Q-3 (External Mode) timing specifications are shown in Figure 27 and describded in Table 55. Figure 27 QMU to Q-5/Q-3 (External Mode) Timing Diagram QACLKI Cycle 1 Cycle 2 Tqes QBCLKI DQDATA Tqeh Tqeh QACLKO QBCLKO NQDATA Tqeomin Tqeomax Tqes Tqep Tqec Tqep Tqec Tqep Tqec Tqep Tqec Tqeomin Tqeomax Freescale Semiconductor, Inc. For More Information On This Product, Go to: www.freescale.com |
|
