6 / 16 page

ADN2526

Rev. A | Page 6 of 16

ABSOLUTE MAXIMUM RATINGS

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

VEE connected to supply ground.

Table 3.

Parameter

Rating

Supply Voltage, VCC to VEE

−0.3 V to +4.2 V

IMODP, IMODN to VEE

1.1 V to 4.75 V

DATAP, DATAN to VEE

VCC − 1.8 V to VCC − 0.4 V

All Other Pins

−0.3 V to VCC + 0.3 V

HBM ESD on IMODP, IMODN

200 V

HBM ESD on All Other Pins

1 kV

Junction Temperature

150°C

Storage Temperature Range

−65°C to +150°C

Soldering Temperature

(Less Than 10 sec)

300°C

ESD CAUTION
