43 / 48 page

M95512-W, M95512-R

Part numbering

Doc ID 11124 Rev 13

43/48

Part numbering

Table 23.

Ordering information scheme

Example:

M95512

–

W MN

P /AB

Device type

M95 = SPI serial access EEPROM

Device function

512 = 512 Kbit (65536 × 8)

512-D = 512 Kbit (65536 × 8) plus Identification page

Operating voltage

W = VCC = 2.5 V to 5.5 V

R = VCC = 1.8 V to 5.5 V

Package

MN = SO8 (150 mil width)

DW = TSSOP8 (169 mil width)

MB = UFDFPN8 (MLP8)

CS = WLCSP

Device grade

6 = Industrial temperature range, –40 to 85 °C.

Device tested with standard test flow

3 = Device tested with high reliability certified flow(1).

Automotive temperature range (–40 to 125 °C)

ST strongly recommends the use of the automotive grade devices for use in an automotive environment.

The high reliability certified flow (HRCF) is described in the quality note QNEE9801. Please ask your

nearest ST sales office for a copy.

Option

blank = Standard packing

T = Tape and reel packing

Plating technology

P or G = ECOPACK® (RoHS compliant)

Process(2)

/AB = F8L

/K = F8H
