UNISONIC TECHNOLOGIES CO., LTD

4051

CMOS IC

www.unisonic.com.tw

1 of 7

Copyright © 2007 Unisonic Technologies Co., Ltd

QW-R502-054.B

8-CHANNEL ANALOG

MULTIPLEXERS/DEMULTIPLEXERS

DESCRIPTION

UTC 4051 is single 8-channel analog multiplexers/demultiplexers

for application as digitally–controlled analog switches.

The device has three binary control inputs and an inhibit input. It

feature low ON impedance and very low OFF leakage current. Control

of analog signals up to the complete supply voltage range can be

achieved.

FEATURES

* Break-Before-Make switching eliminates channel overlap.

* Linearized transfer characteristics

* Implement an SP8T solid state switch effectively.

* Pin–to–Pin Replacement for CD4051

DIP-16

SOP-16

TSSOP-16

*Pb-free plating product number: 4051L

ORDERING INFORMATION

Ordering Number

Normal

Lead Free Plating

Package

Packing

4051-D16-T

4051L-D16-T

DIP-16

Tube

4051-P16-R

4051L-P16-R

TSSOP-16

Tape Reel

4051-P16-T

4051L-P16-T

TSSOP-16

Tube

4051-S16-R

4051L-S16-R

SOP-16

Tape Reel

4051-S16-T

4051L-S16-T

SOP-16

Tube

4051L-D16-T

(1)Packing Type

(2)Package Type

(3)Lead Plating

(1) R: Tape Reel, T: Tube

(2) D16: DIP-16, P16: TSSOP-16, S16: SOP-16

(3) L: Lead Free Plating, Blank: Pb/Sn
