4 / 16 page

ADP197

Rev. 0 | Page 4 of 16

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

VIN to GND

−0.3 V to +6.5 V

VOUT to GND

−0.3 V to VIN

EN to GND

−0.3 V to VIN

Continuous Drain Current

TA = 25°C

±4 A

TA = 85°C

±2.22 A

Continuous Diode Current

−50 mA

Storage Temperature Range

−65°C to +150°C

Operating Junction Temperature Range

−40°C to +105°C

Soldering Conditions

JEDEC J-STD-020

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

Table 3. Typical θJA and ΨJB Values

Package Type

θJA

ΨJB

Unit

6-Ball, 0.5 mm Pitch WLCSP

260

°C/W

ESD CAUTION
