background image
INCHANGE Semiconductor
isc Product Specification
isc Silicon NPN Power Transistor
2SC681
DESCRIPTION
·Collector-Emitter Sustaining Voltage-
: VCEO(SUS)= 70V (Min)
·Low Collector Saturation Voltage-
: VCE(sat)= 2.0V(Max.)@ IC= 5A
APPLICATIONS
·Designed for use in B/W TV horizontal output applications.
ABSOLUTE MAXIMUM RATINGS(Ta=25℃)
SYMBOL
PARAMETER
MAX
UNIT
VCBO
Collector-Base Voltage
200
V
VCEO
Collector-Emitter Voltage
70
V
VEBO
Emitter-Base Voltage
5
V
IC
Collector Current-Continuous
6
A
ICM
Collector Current-Peak
20
A
IB
B
Base Current-Continuous
2
A
PC
Collector Power Dissipation
@TC=25℃
50
W
Tj
Junction Temperature
150
℃
Tstg
Storage Temperature Range
-65~150
℃
THERMAL CHARACTERISTICS
SYMBOL
PARAMETER
MAX
UNIT
Rth j-c
Thermal Resistance,Junction to Case
2.5
℃/W
isc Website：www.iscsemi.cn
