background image
Inchange Semiconductor
Product Specification
2
Silicon NPN Power Transistors
2SC5417
CHARACTERISTICS
Tj=25℃ unless otherwise specified
SYMBOL
PARAMETER
CONDITIONS
MIN
TYP.
MAX
UNIT
VCEO(SUS)
Collector-emitter sustaining voltage
IC=0.1A; IB=0
600
V
VCEsat
Collector-emitter saturation voltage
IC=1.5A; IB=0.3 A
1.0
V
VBEsat
Base-emitter saturation voltage
IC=1.5A; IB=0.3 A
1.5
V
ICBO
Collector cut-off current
VCB=600V; IE=0
10
μA
ICES
Collector cut-off current
VCE=1200V; RBE=0
1.0
mA
IEBO
Emitter cut-off current
VEB=9V; IC=0
1.0
mA
hFE-1
DC current gain
IC=0.1A ; VCE=5V
30
50
hFE-2
DC current gain
IC=1.0A ; VCE=5V
10
Switching times
ts
Storage time
2.5
μs
tf
Fall time
IC=1.5A;IB1=0.3A ;IB2=-0.6A
0.15
μs
