Document Number: 36001

For technical questions, contact: connectors@vishay.com

www.vishay.com

Revision: 16-Feb-09

EB4

Edgeboard Connectors, Dual Readout, 0.100" (2.54 mm) C-C,

Standard and Right Angle Terminals

Vishay Dale

DIMENSIONS in inches (millimeters)

Polarizing Key:

When ordering polarizing keys individually,

specify by the Model Number:

PK-4 between contacts. Hand insertion tool,

TPK-4, provided upon request.

# OF CONTACT

POSITIONS

PER SIDE

ABC

1.435 (36.45)

1.175 (29.85)

0.700 (17.78)

0.860 (21.84)

0.750 (19.05)

1.835 (46.61)

1.575 (40.00)

1.100 (27.94)

1.260 (32.00)

1.150 (29.21)

2.035 (51.69)

1.775 (45.08)

1.300 (33.02)

1.460 (37.08)

1.350 (34.29)

2.335 (59.31)

2.075 (52.70)

1.600 (40.64)

1.760 (44.70)

1.650 (41.91)

2.635 (66.93)

2.375 (60.32)

1.900 (48.26)

2.060 (52.32)

1.950 (49.53)

2.835 (72.01)

2.575 (65.40)

2.100 (53.34)

2.260 (57.40)

2.150 (54.61)

3.035 (77.09)

2.775 (70.48)

2.300 (58.42)

2.460 (62.48)

2.350 (59.69)

3.335 (84.71)

3.075 (78.10)

2.600 (66.04)

2.760 (70.10)

2.650 (67.31)

3.635 (92.33)

3.375 (85.72)

2.900 (73.66)

3.060 (77.72)

2.950 (74.93)

3.835 (97.41)

3.575 (90.80)

3.100 (78.74)

3.260 (82.80)

3.150 (80.01)

3.935 (99.95)

3.675 (93.34)

3.200 (81.28)

3.360 (85.34)

3.250 (82.55)

4.335 (110.11)

4.075 (103.50)

3.600 (91.44)

3.760 (95.50)

3.650 (92.71)

4.435 (112.65)

4.175 (106.04)

3.700 (93.98)

3.860 (98.04)

3.750 (95.25)

4.835 (122.81)

4.575 (116.20)

4.100 (104.14)

4.260 (108.20)

4.150 (105.41)

5.135 (130.43)

4.875 (123.82)

4.400 (111.76)

4.560 (115.82)

4.450 (113.03)

5.235 (132.97)

4.975 (126.36)

4.500 (114.30)

4.660 (118.36)

4.550 (115.57)

5.635 (143.13)

5.375 (136.52)

4.900 (124.46)

5.060 (128.52)

4.950 (125.73)

5.735 (145.67)

5.475 (139.06)

5.000 (127.00)

5.160 (131.06)

5.050 (128.27)

5.835 (148.21)

5.575 (141.60)

5.100 (129.54)

5.260 (133.60)

5.150 (130.81)

6.835 (173.61)

6.575 (167.00)

6.100 (154.94)

6.260 (159.00)

6.150 (156.21)

7.335 (186.31)

7.075 (179.70)

6.600 (167.64)

6.760 (171.70)

6.650 (168.91)

0.287

(7.29)

See table for

contact and

mounting variations

0.250

(6.35)

Typ.

0.430

(10.92)

Typ.

0.610 (15.49)

Typ.

0.180

(4.57)

Typ.

0.060

(1.52)

Typ.

0.050

(1.27)

Typ.

0.342

(8.69)

Typ.

0.365

(9.27)

0.060

(1.52)

R Typ.

0.100

(2.54)

Typ.

0.200

(5.08)

0.300 (7.62)

Depth of

Insertion

0.054 - 0.071 (1.37 - 1.80)

Card Thickness

Section J - J

0.125

(3.17)

Point of

Contact

0.031

(0.787)

0.295

(7.49)

0.150 (3.81)

0.096 ± 0.002

(2.44 ± 0.051)
