background image
Inchange Semiconductor
Product Specification
Silicon NPN Power Transistors
BUL310
DESCRIPTION
・
・With TO-220C package
・High voltage,high speed
・Wide area of safe operation
APPLICATIONS
・Electronic ballasts for fluorescent lighting
・Switch mode power supplies
・Flyback and forward single transistor
low power converters
PINNING
PIN
DESCRIPTION
1
Base
2
Collector;connected to
mounting base
3
Emitter
Absolute maximum ratings(Ta=25℃)
SYMBOL
PARAMETER
CONDITIONS
VALUE
UNIT
VCBO
Collector-base voltage
Open emitter
1000
V
VCEO
Collector-emitter voltage
Open base
500
V
VEBO
Emitter-base voltage
Open collector
9
V
IC
Collector current (DC)
5
A
ICM
Collector current-Peak
tp<5ms
10
A
IB
Base current (DC)
3
A
IBM
Base current-Peak
tp<5ms
4
A
Ptot
Total power dissipation
TC=25℃
75
W
Tj
Maximum operating junction temperature
150
℃
Tstg
Storage temperature
-65~150
℃
THERMAL CHARACTERISTICS
SYMBOL
PARAMETER
VALUE
UNIT
Rth j-case
Thermal resistance junction to case
1.65
℃/W
