LED Power

ZQF60(R) SERIES

60 Watts

http://www.archcorp.com.tw

TEL: +886-2-26989508

FAX: +886-2-26981319

-2-

MECHANICAL DIMENSION

( Top View )

DERATING

BLOCK DIAGRAM

PIN#

SINGLE

1

AC IN (N)

2

AC IN (L)

3

NC

4

+DC OUT

5

-DC OUT

Note:

1. Ripple & Noise are measured at 20MHz of bandwidth with 0.1uF & 47uF parallel capacitor.

2. Please check the derating curve for more details.

3. Input Voltage=115 or 230 VAC

。This is the suitable operation region for LED related application.but please reconfirm special electrical requirements

for some specific ststem design.
