KPY 62-RK
KPY 66-RK
Semiconductor Group
2
1998-05-11
1) Frontside coupling applies pressure onto chip face.
Rearside coupling applies pressure through Kovar centre tube.
Absolute Maximum Ratings
Parameter
Symbol
Limit Values
1)
Unit
Frontside Rearside
Pressure overload
KPY 65 RK
KPY 66 RK
P
MAX
20
50
10
10
bar
Operating temperature range
T
A
− 40 …+ 125
˚C
Storage temperature range
T
stg
− 40 …+ 125
˚C
Supply voltage
V
IN
12
V
Electrical Characteristics
at
T
A = 25 ˚C and VIN = 5 V, unless otherwise specified.
Parameter
Symbol
Limit Values
Unit
min.
typ.
max.
Bridge resistance
R
B
4
−
8k
Ω
Sensitivity
KPY 65 RK
KPY 66 RK
s
3.6
1.1
5.2
2.1
8.0
3.0
mV/
Vbar
Output voltage
KPY 65 RK
KPY 66 RK
V
fin
180
150
260
260
400
370
mV
Offset voltage
P = P
0
V
0
− 25
−+ 25
mV
Linearity error (Best fit straight line)
P
0 = P0 … PN
F
L
%
V
fin
KPY 65
… 66 RK
−± 0.3 ± 0.5
Pressure hysteresis
P
1 = P0, P2 = PN, P3 = P0
KPY 65
… 66 RK
P
H
−± 0.1 −
%
V
fin
