2 / 3 page

UB2K

DUAL TRANSISTOR

UNISONICTECHNOLOGIESCO.,LTD

2 of 3

www.unisonic.com.tw

QW-R218-006.A

ABSOLUTE MAXIMUM RATING (Ta=25°C)

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

VCC

-50

-40

Input Voltage

VIN

+10

IOUT

-30

Output Current

-100

Power Dissipation

+150

Junction Temperature

+150

°C

Storage Temperature

TSTG

-55 ~ +150

°C

Note: Absolute maximum ratings are the values beyond which the device will be damaged permanently.

Absolute maximum ratings are only stress ratings and it is not implied for functional device operation.

ELECTRICAL CHARACTERISTICS (Ta=25°C)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

VI(OFF)

VCC=-5V, IOUT=-100µA

-0.5

Input Voltage

VI(ON)

VOUT=-0.3V, IOUT=-2mA

-3

Output Voltage

VO(ON)

IO/II=-10mA/-0.5mA

-0.1

-0.3

Input Current

IIN

VIN=-5V

-0.18 mA

Output Current

IO(OFF)

VCC=-50V, VIN=0V

-0.5

µA

DC Current Gain

hFE

VOUT=-5V, IOUT=-5mA

Transition Frequency

VCE=-10V, IE=5mA, f=100MHZ (Note)

250

MHz

Input Resistance

32.9

61.1

kΩ

Resistance Ratio

R2/R1

0.8

1.2

Note: Transition frequency of the device
