2 / 2 page

BAV199

Preliminary

DIODE

UNISONICTECHNOLOGIESCO.,LTD

2 of 2

www.unisonic.com.tw

QW-R601-037.a

ABSOLUTE MAXIMUM RATINGS (TA = 25°C, unless otherwise specified)

PARAMETER

SYMBOL

RATINGS

UNIT

Peak Repetitive Reverse Voltage

VRRM

Working Peak Reverse Voltage

VRWM

DC Blocking Voltage

RMS Reverse Voltage

VR(RMS)

Single diode

160

Forward Continuous Current

Double diode

IFM

140

Repetitive Peak Forward Current

IFRM

500

@ t = 1.0μs

4.0

@ t = 1.0ms

1.0

Non-Repetitive Peak Forward Surge

Current

@ t = 1.0s

IFSM

0.5

Power Dissipation (Note 2)

250

Junction Temperature

-65~+150

°C

Storage Temperature

TSTG

-65~+150

°C

Note: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.

1. Absolute maximum ratings are stress ratings only and functional device operation is not implied.

2. Part mounted on FR-4 PC board with recommended pad layout

THERMAL DATA

PARAMETER

SYMBOL

RATINGS

UNIT

Thermal Resistance Junction to Ambient Air (Note 2)

θJA

500

°C/W

ELECTRICAL CHARACTERISTICS (TA =25°C, unless otherwise specified.)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

Reverse Breakdown Voltage (Note 1)

V(BR)R

IR= 100μA

IF= 1.0mA

0.90

IF= 10mA

1.0

IF= 50mA

1.1

Forward Voltage (Note 1)

IF= 150mA

1.25

VR= 75V

5.0

Leakage Current (Note 1)

VR= 75V, TJ= 150°C

Total Capacitance

VR= 0, f = 1.0MHz

Reverse Recovery Time

trr

IF= IR= 10mA, Irr = 0.1 x IR,

RL= 100Ω

3.0

μs

Note: 1. Short duration test pulse to minimize self-heating effect.

UTC assumes no responsibility for equipment failures that result from using products at values that

exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or

other parameters) listed in products specifications of any and all UTC products described or contained

herein. UTC products are not designed for use in life support appliances, devices or systems where

malfunction of these products can be reasonably expected to result in personal injury. Reproduction in

whole or in part is prohibited without the prior written consent of the copyright owner. The information

presented in this document does not form part of any quotation or contract, is believed to be accurate

and reliable and may be changed without notice.
