ADA4610-2
Data Sheet
Rev. A | Page 12 of 20
60
50
40
30
20
0
10
0.01
0.1
1
CAPACITANCE (nF)
OS–
OS+
ADA4610-2
VSY = ±5V
TA = 25°C
AV = +1
RL = 2kΩ
VIN = 100mV p-p
Figure 33. Overshoot vs. Load Capacitance
75
50
25
0
–25
–50
–75
0
1
2
3
4
5
6
7
8
9
10
TIME (µs)
ADA4610-2
VSY = ±15V
TA = 25°C
AV = +1
RL = 2kΩ
CL = 100pF
Figure 34. Small Signal Transient Response
100
10
1
0.001
0.01
0.1
1
10
FREQUENCY (kHz)
ADA4610-2
VSY = ±15V
TA = 25°C
Figure 35. Voltage Noise Density
50
45
40
35
30
0
25
20
15
10
5
0.01
0.1
1
CAPACITANCE (nF)
OS–
OS+
ADA4610-2
VSY = ±15V
TA = 25°C
AV = +1
RL = 2kΩ
VIN = 100mV p-p
Figure 36. Overshoot vs. Load Capacitance
