17 / 20 page  Data Sheet ADM3053 Rev. A | Page 17 of 20 TYPICAL APPLICATIONS Figure 32 is an example circuit diagram using the ADM3053. CAN CONTROLLER 3.3V/5V SUPPLY 100nF 10nF 100nF 10nF CANH CANL RT BUS CONNECTOR 5V SUPPLY 100nF 10µF 10µF 100nF RS ADM3053 TxD RxD ISOLATION BARRIER GND1 GND2 LOGIC SIDE BUS SIDE ENCODE DECODE DECODE ENCODE OSCILLATOR RECTIFIER REGULATOR VISOOUT DIGITAL ISOLATION iCoupler isoPowerDC-TO-DC CONVERTER VIO VISOIN RS CANH CANL VREF REFERENCE VOLTAGE RECEIVER CAN TRANSCEIVER TxD RS RxD VREF GND2 VCC SLOPE/ STANDBY DRIVER PROTECTION VCC Figure 32. Example Circuit Diagram Using the ADM3053 |
|
|
