background image
Data Sheet
ADA4096-2
Rev. A | Page 7 of 20
ABSOLUTE MAXIMUM RATINGS
Table 5.
Parameter
Rating
Supply Voltage
36 V
Input Voltage
Operating Condition
−V ≤ VIN ≤ +V
Overvoltage Condition1
(−V) − 32 V ≤ VIN ≤ (+V) + 32 V
Differential Input Voltage2
±VSY
Input Current
±5 mA
Output Short-Circuit Duration to
GND
Indefinite
Storage Temperature Range
−65°C to +150°C
Operating Temperature Range
−40°C to +125°C
Junction Temperature Range
−65°C to +150°C
Lead Temperature (Soldering,
60 sec)
300°C
1
Performance not guaranteed during overvoltage conditions.
2
Limit the input current to ±5 mA.
Stresses above those listed under Absolute Maximum Ratings
may cause permanent damage to the device. This is a stress
rating only; functional operation of the device at these or any
other conditions above those indicated in the operational
section of this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect
device reliability.
THERMAL RESISTANCE
θJA is specified for the device soldered on a 4-layer JEDEC standard
printed circuit board (PCB) with zero airflow. The exposed pad
is soldered to the application board.
Table 6. Thermal Resistance
Package Type
θJA
θJC
Unit
8-Lead MSOP (RM-8)
142
45
°C/W
8-Lead LFCSP (CP-8-10)
76
43
°C/W
ESD CAUTION
