ADP1046

Data Sheet

Rev. 0 | Page 78 of 96

Table 108. Register 0x6C—Dead Time 4

Bits

Bit Name

R/W

Description

t7 polarity

R/W

0 = positive polarity; 1 = negative polarity.

[6:4]

t7 offset

R/W

This value multiplied by Register 0x70[2:0] determines the t7 offset from nominal timing at no load.

Bit 6

Bit 5

Bit 4

Offset (ns)

t8 polarity

R/W

0 = positive polarity; 1 = negative polarity.

[2:0]

t8 offset

R/W

This value multiplied by Register 0x70[2:0] determines the t8 offset from nominal timing at no load.

Bit 2

Bit 1

Bit 0

Offset (ns)

Table 109. Register 0x6D—Dead Time 5

Bits

Bit Name

R/W

Description

t9 polarity

R/W

0 = positive polarity; 1 = negative polarity.

[6:4]

t9 offset

R/W

This value multiplied by Register 0x70[2:0] determines the t9 offset from nominal timing at no load.

Bit 6

Bit 5

Bit 4

Offset (ns)

t10 polarity

R/W

0 = positive polarity; 1 = negative polarity.

[2:0]

t10 offset

R/W

This value multiplied by Register 0x70[2:0] determines the t10 offset from nominal timing at no load.

Bit 2

Bit 1

Bit 0

Offset (ns)
