ADP1053ACPZ-R7 datasheet(84/84 Pages) AD

84 / 84 page

ADP1053

Data Sheet

Rev. A | Page 84 of 84

OUTLINE DIMENSIONS

0.50

BSC

BOTTOM VIEW

TOP VIEW

PIN 1

INDICATOR

EXPOSED

PAD

PIN 1

INDICATOR

SEATING

PLANE

0.05 MAX

0.02 NOM

0.20 REF

COPLANARITY

0.08

0.30

0.23

0.18

6.10

6.00 SQ

5.90

0.80

0.75

0.70

FOR PROPER CONNECTION OF

THE EXPOSED PAD, REFER TO

THE PIN CONFIGURATION AND

FUNCTION DESCRIPTIONS

SECTION OF THIS DATA SHEET.

0.45

0.40

0.35

0.25 MIN

4.45

4.30 SQ

4.25

COMPLIANT TO JEDEC STANDARDS MO-220-WJJD.

Figure 45. 40-Lead Lead Frame Chip Scale Package [LFCSP_WQ]

6 mm × 6 mm Body, Very Very Thin Quad

(CP-40-10)

Dimensions shown in millimeters

ORDERING GUIDE

Model1

Temperature Range

Package Description

Package Option

ADP1053ACPZ-RL

−40°C to +125°C

40-Lead Lead Frame Chip Scale Package [LFCSP_WQ]

CP-40-10

ADP1053ACPZ-R7

−40°C to +125°C

40-Lead Lead Frame Chip Scale Package [LFCSP_WQ]

CP-40-10

ADP1053DC-EVALZ

ADP1053 Daughter Card Evaluation Board

ADP-I2C-USB-Z

USB to I2C Interface Connector

Z = RoHS Compliant Part.
