AD8274
Rev. C | Page 10 of 16
40
35
30
25
20
15
10
5
0
–40
–20
0
20
40
60
80
100
120
TEMPERATURE (°C)
+SR
–SR
Figure 29. Slew Rate vs. Temperature
FREQUENCY (Hz)
10
100
1k
10k
1
10
100
1k
10k
100k
GAIN = 2
GAIN = ½
Figure 30. Voltage Noise Density vs. Frequency, Referred to Output
1s/DIV
G = ½
G = 2
Figure 31. 0.1 Hz to 10 Hz Voltage Noise, RTO
0.1
0.01
0.001
0.0001
10
100
1k
10k
100k
FREQUENCY (Hz)
22kHz FILTER
VOUT = 10V p-p
RL = 600Ω
GAIN = 2
GAIN = ½
Figure 32. THD + N vs. Frequency, Filter = 22k Hz
0.1
0.01
0.001
0.0001
10
100
1k
10k
100k
FREQUENCY (Hz)
VOUT = 10V p-p
GAIN = 2
GAIN = ½
Figure 33. THD + N vs. Frequency, Filter = 120 kHz
1
0.1
0.01
0.001
0.0001
0
25
5
10
15
20
OUTPUT AMPLITUDE (dBu)
GAIN = ½
f = 1kHz
RL = 2kΩ, 100Ω
RL = 600Ω
Figure 34. THD + N vs. Output Amplitude, G = ½
