1 / 1 page

1.0

1.5

2.0

2.5

3.0

3.5

4.0

DIGI-KEY PART #

ATS PART #

Features & Benefits

Product Details†

Thermal Performance Table

AIR VElocITY

THERMAl RESISTANcE

FT/MIN

200

300

400

500

600

700

800

M/S

°c/W (UNDUcTED)

°c/W (DUcTED)

DIMENSIoN A

DIMENSIoN B

DIMENSIoN c§

DIMENSIoN D

FINISH

37.6

4

56

BlUE-ANoDIZED

For further technical information, please contact Advanced Thermal

Solutions, Inc. at 1-781-769-2800 or www.qats.com

7.8

6.1

4.9

4.1

3.6

3.1

2.8

3.8

ATS1377-ND

Low Profile, High Performance Cooling

Solutions w/Thermal Tape Attachment*

To place an order, please visit www.digikey.com

blueIcE™ heat sinks feature an ultra low profile for

tough-to-cool applications

TIM‡

c675

ATS-60001-c2-R0

* RoHS compliant

‡ TIM = Thermal Interface Material

† Dimensions are measured in millimeters

§ Dimension c = the height of the heat sink shown above

and does not include the height of the attachment method

Designed for high performance in low air velocities

Ideal for telecommunications applications where space is

limited

comes preassembled with high performance thermal

interface material

C

D

A

B
